上海欧朔生产的全伺服水平式卷膜制袋包装机,可实现数据调取,一键式切换;全伺服结构,更加简单稳定、噪音更小;封合采用伺服跟随定位,减少封口允许误差,提升包装美观度;设备采用全新控制系统,提升OEE设备综合效率;具备运转机构监视功能,更加具备安全性;设备更加智能,降低对操作人员的要求.
全伺服水平式卷膜制袋包装机的特点及参数
EQUIPMENT FEATURE AND PARAMETER:
1.可实现数据调取,一键式切换;
Data retrieval ability with one-button switching facility
2.全伺服结构,更加简单稳定、噪音更小;
Fully servo structure, simpler and more stable, less noise
3.封合采用伺服跟随定位,减少封口允许误差,提升包装美观度;
Servo-followed Poistioning sealing, reduce allowable sealing error and improves aesthetics of packaging
4.设备采用全新控制系统,提升OEE设备综合效率;
Adopts a Fully new control system to improve the comprehensive rate of OEE equipment
5.具备运转机构监视功能,更加具备安全性;
Equipped with running mechanism monitoring function, adding better security
6.设备更加智能,降低对操作人员的要求;
The equipment is more intelligent which reduces the requirements for operators
型号 Model | SF-480D | SF-360D | SF-480Q | SF-240 | SF-240D | SF-180 | ||
袋形尺寸范围 Pouch Size |
90*110(Min) 240*350(Max) |
80*110(Min) 180*270(Max) |
60*80(Min) 120*225(Max) |
90*110(Min) 240*350(Max) |
60*80(Min) 120*224(Max) |
90*110(Min) 180*260(Max) |
||
包装容量范围 Filling Capacity | 2500ml | 1200ml | 180ml | 2500ml | 180ml | 1200ml | ||
包装速度 Packaging Capacity | 100-140ppm | 100-140ppm | 200-260ppm | 50-70ppm | 100-140ppm | 50-70ppm | ||
能 耗Energy Consumption |
|
17kw/h | 18kw/h | 16kw/h | 17kw/h | 15kw/h | ||
耗气量 Air Consumption | 300NL/min | 300NL/min | 400NL/min | 300NL/min | 300NL/min | 300NL/min | ||
设 备尺寸 Machine Dimensions |
13200*1580*1850 (L*W*H) |
11000*1700*1850 (L*W*H) |
12800*1240*1500 (L*W*H) |
9000*1500*1850 (L*W*H) |
9500*1500*1850 (L*W*H) |
7650*1500*1850 (L*W*H) |
||
重 量 Weight | 8300kg | 8000kg | 10800kg | 6600kg | 6900kg | 5600kg |
